The AVN-GMCS is a PTPv2 grandmaster clock for use with AoIP applications. IEEE1588-2008 PTPv2 (precision time protocol) is used to synchronise all the nodes within a network. To achieve this one of the nodes must become the master clock and distribute time packets to the others. The AVN-GMCS is designed to perform this role simply [more]
The Analogue video sync board will accept a composite signal of NTSC (525), PAL (625) & SECAM (625) signals covered by SMPTE-170-M (NTSC) and ITU-R BT.470-6 (PAL & SECAM).
The Digital video sync board will accept 270Mbps SD-SDI and HD-SDI signals covered by SMPTE-259-M-C (SD) and SMPTE-292M (HD).
The AES/EBU sync board will accept a digital audio input signal with a sample frequency between 32kHz and 192 kHz. When using the RB-SYE sync board, the Channel Status information that is encoded in the input data signal is copied to all digital output channels on the RB-TGHD.
The Audio Clock sync board will accept a distributed clock running at the desired sample frequency between 32 kHz and 192 kHz. The signal can be differential or single ended TTL level.
Master Clock Generator especially designed to cater for all video and digital audio synchronisation requirements within the post-production, studio & broadcasting industry. -Selectable input reference with auto detection of video formats. -All HD frame rates selectable in progressive scan & interlaced 1080 or 720. -All SD frame rates selectable and available independently of HD outputs. [more]
